ITEM
|
SPEC
|
REMARKS
|
|
Load life under high temperature
|
¡Ó5% |
JIS C 5201-1¡@¡@Rated voltage at 70¢J for 1,000 hours
(4.25.1)¡@¡@¡@¡@
|
|
Load life under high humidity
|
¡Ó5% |
JIS C 5201-1¡@¡@Rated voltage at 40¢J,95% RH for
1,000 hours
(4.24)¡@¡@¡@¡@¡@
|
|
Temp. coeff. of resistance
|
R>1£[. ¡Ó300ppm/¢J
R¡Ø1£[. ¡Ó500ppm/¢J
|
JIS-C-5202 5.2¡@ Room
temp. + 100¢J
¡@¡@¡@¡@¡@¡@¡@¡@
|
|
Short time overload
|
¡Ó1%
|
JIS C 5201-1¡@¡@6.25 times the rated power for 5
seconds
(4.13)¡@¡@¡@¡@¡@
|
|
Temperature cycling
|
¡Ó1% |
JIS C 5201-1¡@¡@5 cycles for ¡V25¢J¡Ó3¢J(30min)¡Froom
temp.
(4.19)¡@¡@¡@¡@¡@ (30min)~ +85¢J¡Ó3¢J(30min) room
temp.(30min)
|
|
Resistance to soldering heat
|
¡Ó1% |
JIS C 5201-1¡@¡@260¢J¡Ó5¢J for 10 seconds(²k¿ü¼Ñ)
(4.18)¡@¡@¡@¡@¡@ 350¢J¡Ó10¢J for 3.5 seconds(¤â²k¿ü)
|
|
Insulation resistance
|
>1,000M£[ |
JIS C 5201-1¡@¡@500 V Insulation test 1min
(4.6.1.1)¡@¡@¡@¡@
|
The RW series are coated with
flame-proof silicon-base
formulation.
