ITEM
|
SPEC
|
REMARKS
|
|
Tolerances
|
F¡G¡Ó1%¡FG¡G¡Ó2%¡F
J¡G¡Ó
5%¡FK¡G¡Ó10%
|
JIS C 5201-1¡@Measuring points on inner edges of
10mm
¡@¡@¡@¡@¡@¡@¡@
|
|
Load life under high temperature
|
¡Ó5%
|
JIS C 5201-1¡@Rated voltage at 70¢J for 1000 hours
(4.25.1)¡@¡@¡@
|
|
Resistance to damp heat
|
¡Ó5%
|
JIS C 5201-1¡@Rated voltage at 40¢J,95% RH for 1000
hours
(4.24)¡@¡@¡@¡@
|
|
Temp. coeff. of resistance
|
R¡Ø1£[¡G¡Ó350ppm/¢J
R>1£[¡G¡Ó200ppm/¢J |
JIS C 5201-1¡@Room temp. + 100¢J
¡@¡@¡@¡@¡@¡@¡@
|
|
Short time overload
|
¡Ó1%
|
JIS C 5201-1¡@6.25 times the rated power for 5
seconds
(4.13)¡@¡@¡@¡@
|
|
Temperature cycling
|
¡Ó1%
|
JIS C 5201-1¡@5 cycles for ¡V25¢J¡Ó3¢J(30min)¡Froom
(4.19)¡@¡@¡@¡@ temp.(30min)~ +85¢J¡Ó3¢J(30min)
¡@¡@¡@¡@¡@¡@¡@room temp.(30min)
|
|
Resistance to soldering heat
|
¡Ó1%
|
JIS C 5201-1¡@260¢J¡Ó5 ¢J for 10 seconds(²k¿ü¼Ñ)
(4.18)¡@¡@¡@¡@ 350¢J¡Ó10 ¢J for 3.5 seconds(¤â²k¿ü)
|
|
Insulation resistance
|
>100M£[
|
JIS C 5201-1¡@500 V Insulation test 1min
(4.6.1.1)¡@¡@¡@
|
Compact type with safety
design of non-flammability
